Bose Pro DM5SE Surface-Mount Loudspeakers (Pair, Black) – 5.25″ Drivers, 125W Peak Power, Weather-Resistant, Clear Full-Range Sound for Commercial Indoor & Outdoor Use





Bose DM5SE Loudspeaker (Pair, Black) – Compact Commercial Ceiling Speakers Delivering Clear, Balanced Sound

The Bose Loudspeaker DM5SE black pair combines advanced acoustic engineering with a sleek, low-profile design, offering a reliable solution for commercial sound reinforcement applications where clarity, coverage, and aesthetics are essential. Ideal for environments ranging from retail stores to offices, hospitality venues, and educational facilities, these compact ceiling speakers deliver clear, full-range audio that enhances background music and voice paging alike.

Designed with both installers and end users in mind, the Bose DM5SE black pair ceiling speakers offer an effortless blend of professional sound quality, flexible system compatibility, and architectural discretion, all packaged in a durable, paintable black enclosure.

---

Sleek, Low-Profile Design with Black Finish for Architectural Integration

The Bose DM5SE pair features a slim, circular grille and enclosure finished in a matte black color, perfect for blending into darker ceilings or spaces where a subtle but refined appearance is preferred. The grille attaches magnetically for a clean, flush installation that preserves ceiling aesthetics without visible screws or hardware.

Paintability further enhances design flexibility, allowing customization to match ceiling colors or finishes precisely. The speakers’ compact dimensions enable installation in confined ceiling spaces, making the DM5SE ideal for a wide range of architectural environments where unobtrusive audio solutions are required.

---

Two-Way Speaker System for Balanced Full-Range Audio

Equipped with a 5.25-inch polypropylene woofer and a 1-inch soft dome tweeter, the DM5SE speakers form a two-way loudspeaker system engineered to deliver clear, balanced sound across a broad frequency range. The woofer provides rich low and mid frequencies, while the tweeter handles crisp, detailed highs.

This design ensures excellent speech intelligibility and musical reproduction, making the DM5SE pair well-suited for background music, paging, and general audio reinforcement in commercial spaces. Bose’s proprietary waveguide technology further refines sound directivity, reducing distortion and enhancing clarity.

---

Wide 110-Degree Dispersion for Consistent Coverage

The DM5SE speakers provide a 110° conical coverage pattern, distributing sound evenly over listening areas to reduce hot spots and audio dropouts. This wide dispersion pattern is especially beneficial in medium-sized rooms, ensuring all occupants receive clear, consistent audio regardless of their position.

This coverage allows for fewer speakers per zone, simplifying system design and reducing installation costs while maintaining a high-quality listening experience.

---

Versatile Power Handling with Multi-Tap Transformer

The Bose DM5SE ceiling speakers include a built-in multi-tap transformer, allowing compatibility with both low-impedance (8-ohm) and high-impedance distributed audio systems (70V/100V). This flexibility makes the DM5SE suitable for diverse commercial audio configurations, from direct drive to complex multi-zone systems.

Power tap settings are easily adjustable via a front-access rotary switch, enabling installers to configure the speakers quickly and without removing them from the ceiling. Available taps include:

• 70V: 16W, 8W, 4W, 2W

• 100V: 16W, 8W, 4W

• 8-ohm bypass for direct low-impedance operation

This capability enables precise audio balancing throughout the space and facilitates integration with existing sound systems.

---

Commercial-Grade Durability and Safety Certifications

Built to endure the demands of commercial installations, the DM5SE pair features a robust steel backcan and grille, certified for plenum installations in air-handling spaces. Compliance with UL 1480A and UL 2043 fire safety standards, along with CE and RoHS environmental certifications, assures installers and building managers of the speakers’ quality and safety.

This construction supports long-term reliable performance even in high-traffic, public-facing commercial spaces.

---

Installation-Friendly Features and Accessories

The DM5SE speakers are designed for fast, code-compliant installation, featuring:

• Quick-hold mounting clamps that securely fasten the speakers to ceiling cutouts without tools, reducing labor time.

• Magnetic, paintable grille that simplifies aesthetic finishing and maintenance.

• Plenum-rated steel backcan enclosure to meet fire safety requirements for commercial buildings.

• Tile bridge accessory included to support suspended ceiling tile installations, preventing tile damage.

• Euroblock connectors for secure, professional-grade wiring connections.

These elements ensure professional, code-compliant installation with minimal hassle.

---

Ideal Applications for the Bose Loudspeaker DM5SE Black Pair

The Bose DM5SE black ceiling speaker pair is a versatile solution tailored to diverse commercial environments, including:

• Retail and hospitality venues — Delivering ambient music and clear voice paging that enhances customer experience.

• Corporate offices and conference rooms — Providing high-quality audio for meetings, presentations, and background music.

• Educational settings — Supporting announcements and media playback in classrooms, lecture halls, and libraries.

• Houses of worship — Offering clear speech and music reproduction in sanctuaries and gathering spaces.

• Healthcare facilities — Creating a soothing environment with background music and clear paging in waiting areas and corridors.

Its wide coverage, balanced sound, and low-profile design make the DM5SE ideal for virtually any indoor commercial space requiring dependable audio reinforcement.

---

Technical Specifications – Bose Loudspeaker DM5SE (Pair, Black)

• Speaker Type: In-ceiling, two-way loudspeaker system

• Drivers:

  • Woofer: 5.25-inch polypropylene cone

  • Tweeter: 1-inch soft dome

• Frequency Response: 70 Hz – 20 kHz (-3 dB)

• Coverage Pattern: 110° conical

• Power Handling: 40 W continuous / 160 W peak

• Sensitivity: 87 dB SPL (1W @ 1m)

• Impedance: 8 ohms nominal

• Transformer Taps:

  • 70V: 16W, 8W, 4W, 2W

  • 100V: 16W, 8W, 4W

  • 8-ohm bypass for low-impedance operation

• Mounting System: Quick-hold spring-loaded clamps

• Grille: Magnetic steel, paintable black

• Enclosure: Steel backcan, plenum rated

• Connector Type: Front-access Euroblock

• Certifications: UL 1480A, UL 2043, CE, RoHS

• Dimensions:

  • Diameter: 260 mm (10.2 in)

  • Depth: 128 mm (5.0 in)

  • Ceiling cutout diameter: 230 mm (9.1 in)

• Weight: Approximately 3.6 kg (7.9 lbs) per speaker

• Finish: Matte black, paintable

---

Why Choose the Bose Loudspeaker DM5SE Black Pair?

The Bose DM5SE pair delivers a perfect balance of professional sound performance, design flexibility, and installation convenience. Its ability to reproduce rich, clear sound with wide coverage, combined with a sleek black finish that integrates discreetly into ceilings, makes it an excellent choice for commercial spaces seeking premium audio solutions.

With flexible power options and compliance with commercial safety standards, the DM5SE speakers offer long-lasting, reliable performance that helps create engaging audio environments in any indoor commercial setting.

---

Conclusion

In conclusion, the Bose Loudspeaker DM5SE black pair ceiling speakers provide exceptional full-range sound, wide dispersion, and flexible installation features within a compact, architecturally friendly design. Their durable build and comprehensive safety certifications make them an excellent solution for a variety of commercial audio applications.

Whether outfitting retail environments, corporate offices, educational facilities, or hospitality venues, the Bose DM5SE pair offers clear, balanced sound with a discreet aesthetic — meeting the demands of professional commercial audio installations with ease.
